1 Bottle infeed table
2 Bottle infeed
3 Bottle discharge
4 Bottle discharge conveyor
5 Central gear drive
6 Flushing
7 Caustic pre-spraying
8 Caustic-II spraying
9 Caustic I-soaking
10 Caustic-I spraying
11 Caustic flushing
12 Hot caustic spraying
13 Residual caustic blow off
14 Warm-water spraying

16 Cold-water spraying
17 On/off warmwater pre-spraying
18 On/off freshwater spraying
19 On/off heated warmwater pre-spraying
22 Residual water blow off
23 Pre-soaking
25 Drain
27 Dosage for caustic soaking tank
28 Plate heat exchanger heat recovery
30 Label discharger

31 Shards removal drain
32 Control cabinet
33 Lighting
34 Control cabinet ventilation
35 Overflow
36 Heat exchanger
37 Vapor exhaust
38 Foam insulation
41 Vapor extraction for bottle infeed
42 Infeed table drive
43 Solenoid valve
